G1-24V-SW Standard Version NoDecal
- Item No.KMS05
- CategoryElectric Dirt Bikes
- Vehicle Dimensions1020 × 460 × 600 mm
- Wheelbase730 mm
- Seat Height420 mm
- Minimum Ground Clearance120–125 mm
- Speed Settings8 / 12 / 20 km/h (three selectable speeds)
- Range5–8 km
- Battery24V 4.5Ah lead-acid battery
- Maximum Load Capacity35 kg
G1 Standard 24V Kids Electric Dirt Bike, 4.5Ah
The G1-24V-SW Standard is the no-decal G1 kids electric dirt bike with a 24V 4.5Ah lead-acid battery. Its 12-inch wheels, 420 mm seat height and brushless hub motor provide a distinct configuration for buyers comparing the Standard and Premium versions.
Configuration highlights
- Standard battery configuration: Battery energy is specified at 108Wh, with a listed range of 5–8 km and a maximum load of 35 kg.
- Three selectable speeds: The listed speed settings are 8, 12 and 20 km/h. Motor output is 180W rated and 450W peak.
- Compact chassis: The iron frame has a 730 mm wheelbase and overall dimensions of 1020 × 460 × 600 mm. A rear disc brake and 12-inch front and rear wheels are specified.
- No-decal equipment package: This Standard version has no decals. Headlight and horn are not included. Net weight is 17.8 kg and the listed export carton measures 88 × 24 × 47 cm.
Complete technical specifications
| Parameter | Specification |
|---|---|
| Vehicle Dimensions | 1020 × 460 × 600 mm |
| Wheelbase | 730 mm |
| Seat Height | 420 mm |
| Minimum Ground Clearance | 120–125 mm |
| Maximum Speed | 8 / 12 / 20 km/h (three selectable speeds) |
| Range | 5–8 km |
| Maximum Load Capacity | 35 kg |
| Battery Type | 24V 4.5Ah lead-acid battery |
| Battery Energy | 108 Wh |
| Charger Voltage / Current | 24V 1.5A battery charger |
| Battery Cycle Life | 500 cycles; ≥80% remaining capacity |
| Motor Type | Brushless hub motor |
| Rated Motor Power | 180 W |
| Peak Motor Power | 450 W |
| Controller | 24V / 45A |
| Charger | 1.5A charger (CE certified) |
| Headlight & Horn | Not included |
| Frame Material | Iron frame |
| Frame Finish | Powder coating |
| Front / Rear Tires | Front: 12-inch / Rear: 12-inch |
| Brakes | Rear disc brake |
| Saddle | Four-layer elastic leather with high-elasticity sponge |
| Export Packaging | Oil-film carton with EPE foam |
| Gross / Net Weight | 20.8 kg / 17.8 kg |
| Colors | Black / Red / Orange / White / Custom colors |
| Lead Time | 30 days |
| 40HQ Container Loading Quantity | 623 units |
| Packaging Dimensions | 88 × 24 × 47 cm |
Speed, range, charging time and battery-life figures are listed specifications. Actual results vary with rider load, terrain, riding speed, temperature and battery condition.
Compare related configurations
The Premium version includes decals and a larger 24V 6Ah battery, with a specified range of 8–12 km and a 50 kg maximum load. Headlight and horn are optional on Premium. See the G1-24V-SW Premium Version Decal specification or browse all KMS electric motorcycle models.
Frequently asked questions
What distinguishes Standard from Premium?
The main listed differences are battery capacity, range, maximum load, decals and lighting options. The Standard model uses a 24V 4.5Ah lead-acid battery and has no decals.
Is this suitable for every child?
No single fit suits every rider. Check the 420 mm seat height, vehicle dimensions and 35 kg maximum load, and confirm rider suitability. Adult supervision and appropriate protective equipment are necessary.
Request a quotation
Contact KMS Motors (Yongkang Komoshi Technology Co., Ltd.) with model G1-24V-SW Standard Version NoDecal, quantity, preferred colors and destination country or port. Ask the team to confirm the final configuration, current lead time and export packing for your order. Contact KMS Motors.
